SERVO TEAM CAJA DE ALUMINIO, PIÑONERIA DE TITANIO Y MOTOR CORELESS, ALTO VOLTAJE

- Full CNC machined alloy case
- High Voltage 6.0 - 8.4V
- Titanium gears
- Ball Raced
- Coreless motor
- Ultra high speed and torque
- Water resistant

Tech Specs:

Voltage range 6.0 - 8.4V
Speed @ 6.0V 0.07 sec/60°
Speed @ 7.4V 0.06 sec/60°
Speed @ 8.4V 0.05 sec/60°
Torque @ 6.0V 11.8 kg/cm
Torque @ 7.4V 14.4 kg/cm
Torque @ 8.4V 16.5 kg/cm
Dimensions (mm) 40.5x20.5x36
Weight 72g

INFORMACIÓN DEL PRODUCTO:

KEY FEATURES

- Ideal for 1/10 on road applications
- incredible efficiency and low power consumption
- Aluminium case for good heat dissipation
- NMB dual main bearings
- 25T output shaft

Application :
1/10 On-road, 1/10 Off-road, 1/8 On-road, 1/8 Off-road

operating speed (6.0v): 0.07 sec/60 degrees at no load
operating speed (7.4v): 0.06 sec/60 degrees at no load
stall torque (6.0v): 9.0kg.cm (125.0 oz/in)
stall torque (7.4v): 12.0kg.cm (166.6 oz/in)

Ideal for 1/8 on road and 1/5 off road scale applications

Superior Holding Torque

Incredible efficiency and low power consumption

Standard dimension make it perfect for vehicles that can benefit from a high quality servo

CNC Machined aluminum case for exceptional cooling

Programmable High torque Brushless servo

SSR mode compatible

25T output shaft

2 μsec Dead Band

1-Year Limited Warranty

Type: Digital
Bearing: Dual
Motor Type: Brushless
Gear Type: Metal
Gear Material: Steel
control system: pulse width control
working frequence: 1520μs / 330hz
operating voltage: dc6.0-8.4v
operating temperature range: -10 to + 60 degree
operating speed (6.0v): 0.11 sec/60 degrees at no load
operating speed (7.4v): 0.078 sec/60 degrees at no load
operating speed (8.4v): 0.07 sec/60 degrees at no load
stall torque (6.0v): 50.0kg.cm (694.4 oz/in)
stall torque (7.4v): 55.0kg.cm (763.8 oz/in)
stall torque (8.4v): 60.0kg.cm (833.2 oz/in)
potentiometer drive: direct drive
dimensions: 40.0 x 20.0 x 39.2 mm /1.57 x 0.79 x 1.54 in
weight: 82.0g (2.89 oz)
connector wire length: jr 300 mm

INFORMACIÓN DEL PRODUCTO:

‎El Servo SRT W45 es un servo HV con hasta 45 kg de torque e impermeable, ideal como servo de dirección para rastreadores debido a sus piñóns de acero y titanio.‎

‎Características:‎

‎• Ideal para 1/8 y 1/10 On-Road y Off-Road, rastreador, etc..‎

‎• Caja de aluminio‎

‎• Impermeable‎

‎• Precisión superior‎

‎• Rodamientos principales duales NMB‎

‎• Dientes de piñón de salida 25T‎

Type: Digital
Bearing: Dual
Motor Type: Brushless
Gear Type: Metal
Gear Material: Steel
control system: pulse width control
working frequence: 1520μs / 330hz
operating voltage: dc6.0-8.4v
operating temperature range: -10 to + 60 degree
operating speed (6.0v): 0.15 sec/60 degrees at no load
operating speed (7.4v): 0.11 sec/60 degrees at no load
operating speed (8.4v): 0.10 sec/60 degrees at no load
stall torque (6.0v): 55.0kg.cm (763.8 oz/in)
stall torque (7.4v): 65.0kg.cm (902.7 oz/in)
stall torque (8.4v): 75.0kg.cm (1041.6 oz/in)
potentiometer drive: direct drive
dimensions: 40.0 x 20.0 x 39.2 mm /1.57 x 0.79 x 1.54 in
weight: 82.0g (2.89 oz)
connector wire length: jr 300 mm

INFORMACIÓN DEL PRODUCTO:

‎CARACTERÍSTICAS CLAVE‎

‎- Ideal para 1/10 ON ROAD y‎‎ 1/8‎‎ OFF ROAD‎

‎ - Caja de aluminio intermedio - Rodamientos principales duales NMB - Impermeable superior - Eje de salida 25T‎

‎Aplicación :‎‎ ‎
‎ 1/10 en carretera, 1/10 todoterreno, 1/8 en carretera, 1/8 todoterreno, así como aviones y jets a gran escala y barco eléctrico‎

INFORMACIÓN DEL PRODUCTO:

El Servo SRT W35 es un servo HV con hasta 35kg de torque y resistente al agua ideal como servo de dirección para crawlers por sus piñones de acero y titanio.

Características:
• Ideal para 1/8 y 1/10 On-Road and Off-Road, crawler, etc..
• Caja de aluminio
• Waterproof
• Precisión superior
• NMB dual rodamientos principales
• 25T dientes piñon salida

Servo dimensions Standard

Servo type Digital

Thrust at 6.0V [kg/cm] 31

Thrust at 7.4V [kg/cm] 37

Speed at 6.0V [s/60st.] 0.14

Speed at 7.4V [s/60st.] 0.11

Servo gears Metal

Ball bearings 2×

High-voltage Yes

Power supply [V] 5 - 8.4

Length [mm] 40.5

Width [mm] 21

Height [mm] 38.4

Weight [g] 84

Intended for On-road cars,Off-road cars

S.BUS Yes

S.BUS2 Yes

SR mode Yes, w/ T7PX/T7PXR/T7XC a R334SBS(-E)

Water resistance Splash-resistant

Servo dimensions Standard

Servo type Digital

Thrust at 6.0V [kg/cm] 31

Thrust at 7.4V [kg/cm] 37

Speed at 6.0V [s/60st.] 0.14

Speed at 7.4V [s/60st.] 0.11

Servo gears Metal

Ball bearings 2×

High-voltage Yes

Power supply [V] 5 - 8.4

Length [mm] 41

Width [mm] 21

Height [mm] 38

Weight [g] 74

Intended for Aeroplanes,Helicopters,On-road cars,Off-road cars,Sailing boats,Boats

S.BUS Yes

S.BUS2 Yes

SR mode No

Water resistance Splash-resistant

Éste es el Servo RSX8 Brushless de 37 Kg. y 0.075 s. de Ultimate Racing para coches de 1/8 que cumple con todos los requisitos de durabilidad, rendimiento y calidad necesarios para el más alto nivel de competición. Sirve tanto para dirección como para gas/freno.

INFORMACIÓN DEL PRODUCTO:

PRODUCT SPECIFICATIONS

Type: Digital
Bearing: Dual
Motor Type: DC
Gear Type: Metal
Gear Material: Copper & Alu
control system: pulse width control
working frequence: 1520μs / 330hz
operating voltage: dc4.8-7.4v
operating temperature range: -10 to + 60 degree
operating speed (4.8v): 0.16 sec/60 degrees at no load
operating speed (6.0v): 0.12 sec/60 degrees at no load
operating speed (7.4v): 0.10 sec/60 degrees at no load
stall torque (4.8v): 1.9kg.cm (26.4 oz/in)
stall torque (6.0v): 2.5kg.cm (34.7 oz/in)
stall torque (7.4v): 2.8kg.cm (38.9 oz/in)
potentiometer drive: direct drive
dimensions: 22.5x12.5x24.0 mm /0.89x0.49x0.94 in
weight: 16.0g (0.56 oz)
connector wire length: jr 300 mm

SERVO TEAM CAJA DE ALUMINIO, PIÑONERIA DE TITANIO Y MOTOR CORELESS, ALTO VOLTAJE

Features:

- Full CNC machined alloy case
- High Voltage 6.0 - 8.4V
- Titanium gears
- Ball Raced
- Coreless motor
- Ultra high speed and torque
- Water resistant

Tech. Specs:

Voltage range 6.0 - 8.4V
Speed @ 6.0V 0.09 sec/60°
Speed @ 7.4V 0.08 sec/60°
Speed @ 8.4V 0.07 sec/60°
Torque @ 6.0V 18.3 kg/cm
Torque @ 7.4V 22.6 kg/cm
Torque @ 8.4V 25.6 kg/cm
Dimensions (mm) 40.5x20.5x36
Weight 72g

operating speed (6.0v): 0.08 sec/60 degrees at no load
operating speed (7.4v): 0.065 sec/60 degrees at no load
operating speed (8.4v): 0.053 sec/60 degrees at no load
stall torque (6.0v): 25.0kg.cm (347.2 oz/in)
stall torque (7.4v): 30.0kg.cm (416.6 oz/in)
stall torque (8.4v): 35.0kg.cm (486.1 oz/in)

Ideal for 1/8 on road and 1/5 off road scale applications

Superior Holding Torque

Incredible efficiency and low power consumption

Standard dimension make it perfect for vehicles that can benefit from a high quality servo

CNC Machined aluminum case for exceptional cooling

Programmable High torque Brushless servo

SSR mode compatible

25T output shaft

2 μsec Dead Band

1-Year Limited Warranty
