Type: Digital
Bearing: Dual
Motor Type: Brushless
Gear Type: Metal
Gear Material: Steel
control system: pulse width control
working frequence: 1520μs / 330hz
operating voltage: dc6.0-8.4v
operating temperature range: -10 to + 60 degree
operating speed (6.0v): 0.11 sec/60 degrees at no load
operating speed (7.4v): 0.078 sec/60 degrees at no load
operating speed (8.4v): 0.07 sec/60 degrees at no load
stall torque (6.0v): 50.0kg.cm (694.4 oz/in)
stall torque (7.4v): 55.0kg.cm (763.8 oz/in)
stall torque (8.4v): 60.0kg.cm (833.2 oz/in)
potentiometer drive: direct drive
dimensions: 40.0 x 20.0 x 39.2 mm /1.57 x 0.79 x 1.54 in
weight: 82.0g (2.89 oz)
connector wire length: jr 300 mm

SERVO TEAM CAJA DE ALUMINIO, PIÑONERIA DE TITANIO Y MOTOR CORELESS, ALTO VOLTAJE

Features:

- Full CNC machined alloy case
- High Voltage 6.0 - 8.4V
- Titanium gears
- Ball Raced
- Coreless motor
- Ultra high speed and torque
- Water resistant

Tech. Specs:

Voltage range 6.0 - 8.4V
Speed @ 6.0V 0.09 sec/60°
Speed @ 7.4V 0.08 sec/60°
Speed @ 8.4V 0.07 sec/60°
Torque @ 6.0V 18.3 kg/cm
Torque @ 7.4V 22.6 kg/cm
Torque @ 8.4V 25.6 kg/cm
Dimensions (mm) 40.5x20.5x36
Weight 72g

Especificaciones:

Par @8.4V: 55 kg-cm / 763.8 oz-in

Velocidad @8.4V: 0.055 seg / 60°

Par @7.4V: 40 kg-cm / 555.5 oz-in

Velocidad @7.4V: 0.07 seg / 60°

Dimensiones (L x An x Al en mm): 40.3 x 20.2 x 38.7

Peso: 70 g

INFORMACIÓN DEL PRODUCTO:

KEY FEATURES

- Ideal for 1/8 on road and 1/8 off road scale applications
- Superior Holding Torque
- incredible efficiency and low power consumption
- Standard dimension make it perfect for vehicles that can benefit from a high quality servo
- CNC Machined aluminium case for exceptional cooling
- NMB dual main bearings
- 25T output shaft
- HD 4096 Resolution
- 2 μsec Dead Band

Servo - Savox SA-2273SG Plus - Alto Voltaje - Digital - Brushless - Engranajes de Acero

El Savox SA-2273SG Plus es un servo digital brushless de alto voltaje que combina tecnología de vanguardia con una resolución súper alta de 12 bits (4096 pasos).

Los servos de la serie “Plus” cuentan con arranque suave (Soft Start) y compatibilidad con Sanwa SSR.

Características:

Exclusivo tren de engranajes de acero.

Capaz de operar en alto voltaje (HV).

Motor brushless para un funcionamiento suave y eficiente.

Ideal para buggies 1/8 y aviones de gran escala.

Especificaciones técnicas:

Par @6V: 23.0 kg / 319.4 oz-in

Par @7.4V: 28.0 kg / 388.8 oz-in

Velocidad @6V: 0.12 seg / 60°

Velocidad @7.4V: 0.095 seg / 60°

Dimensiones (L x An x Al en mm): 40.3 x 20.2 x 38.7

Peso: 69.0 g

Servo - Serie "Monster" Performance - Digital - Alto Voltaje - Brushless - Engranajes de Acero - Carcasa de Aluminio

La potente serie "Monster" Performance de Savox utiliza una carcasa completamente de aluminio y tecnología exclusiva de motor y controlador brushless para aumentar la potencia hasta un 35% en comparación con generaciones anteriores de servos.

Servo dimensions Standard

Servo type Digital

Thrust at 6.0V [kg/cm] 31

Thrust at 7.4V [kg/cm] 37

Speed at 6.0V [s/60st.] 0.14

Speed at 7.4V [s/60st.] 0.11

Servo gears Metal

Ball bearings 2×

High-voltage Yes

Power supply [V] 5 - 8.4

Length [mm] 41

Width [mm] 21

Height [mm] 38

Weight [g] 74

Intended for Aeroplanes,Helicopters,On-road cars,Off-road cars,Sailing boats,Boats

S.BUS Yes

S.BUS2 Yes

SR mode No

Water resistance Splash-resistant

Descripción

Type: Digital

Bearing: Dual

Motor Type: Brushless

Gear Type: Metal

Gear Material: Steel

control system: pulse width control

working frequence: 1520μs / 330hz

operating voltage: dc6.0-8.4v

operating temperature range: -10 to + 60 degree

operating speed (6.0v): 0.11 sec/60 degrees at no load

operating speed (7.4v): 0.078 sec/60 degrees at no load

operating speed (8.4v): 0.07 sec/60 degrees at no load

stall torque (6.0v): 50.0kg.cm (694.4 oz/in)

stall torque (7.4v): 55.0kg.cm (763.8 oz/in)

stall torque (8.4v): 60.0kg.cm (833.2 oz/in)

potentiometer drive: direct drive

dimensions: 40.0 x 20.0 x 39.2 mm /1.57 x 0.79 x 1.54 in

weight: 82.0g (2.89 oz)

connector wire length: jr 300 mm

INFORMACIÓN DEL PRODUCTO:

‎CARACTERÍSTICAS CLAVE‎

‎- Ideal para 1/10 en carretera y 1/8‎

‎ ‎

‎ aplicaciones fuera de la‎

‎ carretera‎

‎ - Caja de aluminio‎

‎intermedia - Rodamientos principales duales NMB - Impermeable superior - Eje de salida 25T‎‎Aplicación: ‎‎ ‎

‎1/10 en carretera, 1/10 off-road, 1/8 on-road, 1/8 off-road así como aviones y jets a gran escala y barco eléctrico‎

Servo - Serie "Monster" Performance - Digital - Alto Voltaje - Brushless - Engranaje de Acero - Carcasa de Aluminio

La potente serie "Monster" Performance de Savox utiliza una carcasa completamente de aluminio y tecnología exclusiva de motor y controlador brushless para aumentar la potencia hasta un 35% en comparación con generaciones anteriores de servos.

Ideal for 1/8 on road and 1/5 off road scale applications

Superior Holding Torque

Incredible efficiency and low power consumption

Standard dimension make it perfect for vehicles that can benefit from a high quality servo

CNC Machined aluminum case for exceptional cooling

Programmable High torque Brushless servo

SSR mode compatible

25T output shaft

2 μsec Dead Band

1-Year Limited Warranty

Descripción

Type: Digital

Bearing: Dual

Motor Type: Brushless

Gear Type: Metal

Gear Material: Steel

control system: pulse width control

working frequence: 1520μs / 330hz

operating voltage: dc6.0-8.4v

operating temperature range: -10 to + 60 degree

operating speed (6.0v): 0.15 sec/60 degrees at no load

operating speed (7.4v): 0.11 sec/60 degrees at no load

operating speed (8.4v): 0.10 sec/60 degrees at no load

stall torque (6.0v): 55.0kg.cm (763.8 oz/in)

stall torque (7.4v): 65.0kg.cm (902.7 oz/in)

stall torque (8.4v): 75.0kg.cm (1041.6 oz/in)

potentiometer drive: direct drive

dimensions: 40.0 x 20.0 x 39.2 mm /1.57 x 0.79 x 1.54 in

weight: 82.0g (2.89 oz)

connector wire length: jr 300 mm

Type: Digital
Bearing: Dual
Motor Type: Brushless
Gear Type: Metal
Gear Material: Steel
control system: pulse width control
working frequence: 1520μs / 330hz
operating voltage: dc6.0-8.4v
operating temperature range: -10 to + 60 degree
operating speed (6.0v): 0.15 sec/60 degrees at no load
operating speed (7.4v): 0.11 sec/60 degrees at no load
operating speed (8.4v): 0.10 sec/60 degrees at no load
stall torque (6.0v): 55.0kg.cm (763.8 oz/in)
stall torque (7.4v): 65.0kg.cm (902.7 oz/in)
stall torque (8.4v): 75.0kg.cm (1041.6 oz/in)
potentiometer drive: direct drive
dimensions: 40.0 x 20.0 x 39.2 mm /1.57 x 0.79 x 1.54 in
weight: 82.0g (2.89 oz)
connector wire length: jr 300 mm

Features:

- Full CNC machined alloy case
- Digital LHV 5.0 - 8.4V
- Metal gears
- Ball Raced
- Core DC motor
- High speed and torque
- IP67 Waterproof

Tech. Specs:

Voltage range 5.0 - 8.4V
Speed @ 6.0V 0.15 sec/60°
Speed @ 7.4V 0.13 sec/60°
Speed @ 8.4V 0.11 sec/60°
Torque @ 6.0V 17.7 kg/cm
Torque @ 7.4V 23.6 kg/cm
Torque @ 8.4V 27.3 kg/cm
Dimensions (mm) 40.4x20.4x36.7
Weight 75g / 2.55oz

INFORMACIÓN DEL PRODUCTO:

‎El Servo SRT W45 es un servo HV con hasta 45 kg de torque e impermeable, ideal como servo de dirección para rastreadores debido a sus piñóns de acero y titanio.‎

‎Características:‎

‎• Ideal para 1/8 y 1/10 On-Road y Off-Road, rastreador, etc..‎

‎• Caja de aluminio‎

‎• Impermeable‎

‎• Precisión superior‎

‎• Rodamientos principales duales NMB‎

‎• Dientes de piñón de salida 25T‎

operating speed (6.0v): 0.08 sec/60 degrees at no load
operating speed (7.4v): 0.065 sec/60 degrees at no load
operating speed (8.4v): 0.053 sec/60 degrees at no load
stall torque (6.0v): 25.0kg.cm (347.2 oz/in)
stall torque (7.4v): 30.0kg.cm (416.6 oz/in)
stall torque (8.4v): 35.0kg.cm (486.1 oz/in)
