Ideal for 1/8 on road and 1/5 off road scale applications

Superior Holding Torque

Incredible efficiency and low power consumption

Standard dimension make it perfect for vehicles that can benefit from a high quality servo

CNC Machined aluminum case for exceptional cooling

Programmable High torque Brushless servo

SSR mode compatible

25T output shaft

2 μsec Dead Band

1-Year Limited Warranty

Power Supply: 6.0V~7.4V
Speed (6.0V) : 0.12 sec/60°, (7.4V) : 0.09 sec/60°
Stall Torque (6.0V) : 31.4kg-cm, (7.4V): 40.2kg-cm

operating speed (6.0v): 0.07 sec/60 degrees at no load
operating speed (7.4v): 0.06 sec/60 degrees at no load
stall torque (6.0v): 9.0kg.cm (125.0 oz/in)
stall torque (7.4v): 12.0kg.cm (166.6 oz/in)

SERVO TEAM CAJA DE ALUMINIO, PIÑONERIA DE TITANIO Y MOTOR CORELESS, ALTO VOLTAJE

- Full CNC machined alloy case
- High Voltage 6.0 - 8.4V
- Titanium gears
- Ball Raced
- Coreless motor
- Ultra high speed and torque
- Water resistant

Tech Specs:

Voltage range 6.0 - 8.4V
Speed @ 6.0V 0.07 sec/60°
Speed @ 7.4V 0.06 sec/60°
Speed @ 8.4V 0.05 sec/60°
Torque @ 6.0V 11.8 kg/cm
Torque @ 7.4V 14.4 kg/cm
Torque @ 8.4V 16.5 kg/cm
Dimensions (mm) 40.5x20.5x36
Weight 72g

Futaba HPS-CT702 (30kg 0.07s/60°)

Servo dimensions Standard

Servo type Digital

Thrust at 6.0V [kg∙cm] 23

Thrust at 7.4V [kg∙cm] 30

Speed at 6.0V [s/60st.] 0.08

Speed at 7.4V [s/60st.] 0.07

Servo gears Metal

Ball bearings 2×

High-voltage Yes

Power supply [V] 4.8 - 8.4

Length [mm] 40.5

Width [mm] 21

Height [mm] 26.2

Weight [g] 53

Intended for On-road cars,Off-road cars

S.BUS Yes

S.BUS2 Yes

SR mode Yes

Water resistance Splash-resistant

Type: Digital
Bearing: Dual
Motor Type: Brushless
Gear Type: Metal
Gear Material: Steel
control system: pulse width control
working frequence: 1520μs / 330hz
operating voltage: dc6.0-8.4v
operating temperature range: -10 to + 60 degree
operating speed (6.0v): 0.15 sec/60 degrees at no load
operating speed (7.4v): 0.11 sec/60 degrees at no load
operating speed (8.4v): 0.10 sec/60 degrees at no load
stall torque (6.0v): 55.0kg.cm (763.8 oz/in)
stall torque (7.4v): 65.0kg.cm (902.7 oz/in)
stall torque (8.4v): 75.0kg.cm (1041.6 oz/in)
potentiometer drive: direct drive
dimensions: 40.0 x 20.0 x 39.2 mm /1.57 x 0.79 x 1.54 in
weight: 82.0g (2.89 oz)
connector wire length: jr 300 mm

Éste es el Servo RSX8 Brushless de 37 Kg. y 0.075 s. de Ultimate Racing para coches de 1/8 que cumple con todos los requisitos de durabilidad, rendimiento y calidad necesarios para el más alto nivel de competición. Sirve tanto para dirección como para gas/freno.

Type: Digital
Bearing: Dual
Motor Type: Brushless
Gear Type: Metal
Gear Material: Steel
control system: pulse width control
working frequence: 1520μs / 330hz
operating voltage: dc6.0-8.4v
operating temperature range: -10 to + 60 degree
operating speed (6.0v): 0.11 sec/60 degrees at no load
operating speed (7.4v): 0.078 sec/60 degrees at no load
operating speed (8.4v): 0.07 sec/60 degrees at no load
stall torque (6.0v): 50.0kg.cm (694.4 oz/in)
stall torque (7.4v): 55.0kg.cm (763.8 oz/in)
stall torque (8.4v): 60.0kg.cm (833.2 oz/in)
potentiometer drive: direct drive
dimensions: 40.0 x 20.0 x 39.2 mm /1.57 x 0.79 x 1.54 in
weight: 82.0g (2.89 oz)
connector wire length: jr 300 mm

INFORMACIÓN DEL PRODUCTO:

KEY FEATURES

- Ideal for 1/10 on road applications
- incredible efficiency and low power consumption
- Aluminium case for good heat dissipation
- NMB dual main bearings
- 25T output shaft

Application :
1/10 On-road, 1/10 Off-road, 1/8 On-road, 1/8 Off-road

Servo dimensions Standard

Servo type Digital

Thrust at 6.0V [kg/cm] 31

Thrust at 7.4V [kg/cm] 37

Speed at 6.0V [s/60st.] 0.14

Speed at 7.4V [s/60st.] 0.11

Servo gears Metal

Ball bearings 2×

High-voltage Yes

Power supply [V] 5 - 8.4

Length [mm] 40.5

Width [mm] 21

Height [mm] 38.4

Weight [g] 84

Intended for On-road cars,Off-road cars

S.BUS Yes

S.BUS2 Yes

SR mode Yes, w/ T7PX/T7PXR/T7XC a R334SBS(-E)

Water resistance Splash-resistant

Servo dimensions Standard

Servo type Digital

Thrust at 6.0V [kg/cm] 31

Thrust at 7.4V [kg/cm] 37

Speed at 6.0V [s/60st.] 0.14

Speed at 7.4V [s/60st.] 0.11

Servo gears Metal

Ball bearings 2×

High-voltage Yes

Power supply [V] 5 - 8.4

Length [mm] 41

Width [mm] 21

Height [mm] 38

Weight [g] 74

Intended for Aeroplanes,Helicopters,On-road cars,Off-road cars,Sailing boats,Boats

S.BUS Yes

S.BUS2 Yes

SR mode No

Water resistance Splash-resistant

Features:

- Full CNC machined alloy case
- Digital LHV 5.0 - 8.4V
- Metal gears
- Ball Raced
- Core DC motor
- High speed and torque
- IP67 Waterproof

Tech. Specs:

Voltage range 5.0 - 8.4V
Speed @ 6.0V 0.15 sec/60°
Speed @ 7.4V 0.13 sec/60°
Speed @ 8.4V 0.11 sec/60°
Torque @ 6.0V 17.7 kg/cm
Torque @ 7.4V 23.6 kg/cm
Torque @ 8.4V 27.3 kg/cm
Dimensions (mm) 40.4x20.4x36.7
Weight 75g / 2.55oz

INFORMACIÓN DEL PRODUCTO:

KEY FEATURES

- Ideal for 1/10 on road and 1/8 off road scale applications,  as well as large scale airplanes and jets
- incredible efficiency and low power consumption
- 2 μsec Dead Band

Application :
1/10 On-road, 1/10 Off-road, 1/8 On-road, 1/8 Off-road & 600 700/ Helicopter

operating speed (6.0v): 0.08 sec/60 degrees at no load
operating speed (7.4v): 0.065 sec/60 degrees at no load
operating speed (8.4v): 0.053 sec/60 degrees at no load
stall torque (6.0v): 25.0kg.cm (347.2 oz/in)
stall torque (7.4v): 30.0kg.cm (416.6 oz/in)
stall torque (8.4v): 35.0kg.cm (486.1 oz/in)

Ideal for 1/8 on road and 1/5 off road scale applications

Superior Holding Torque

Incredible efficiency and low power consumption

Standard dimension make it perfect for vehicles that can benefit from a high quality servo

CNC Machined aluminum case for exceptional cooling

Programmable High torque Brushless servo

SSR mode compatible

25T output shaft

2 μsec Dead Band

1-Year Limited Warranty

Servo dimensions Standard

Servo type Digital

Thrust at 7.4V [kg/cm] 30

Speed at 7.4V [s/60st.] 0.07

Servo gears Metal

Ball bearings 2×

High-voltage Yes

Power supply [V] 4.8 - 8.4

Length [mm] 40.5

Width [mm] 21

Height [mm] 26.2

Weight [g] 53

Intended for On-road cars,Off-road cars

S.BUS Yes

S.BUS2 Yes

SR mode Yes

Water resistance Splash-resistant
